SPEAKER COMPONENT XSYS 15 Inch TYPE RH1597

GENEREAL SPECIFICATION
Nominal Diameter : 380Mm/15Inch
Power Rating : 600Watt
Nominal Impendance : 80hm
Sensitivity : 96Db
Frequency Range : 40-3500Hz
Chassis Type : Stamp Steel
Magnet Type : Ferrite
Magnet Size : 190*90*20Mm
Magnet Weight : 2.2Kg/77.70z
Voice Coil Diameter : 75.5Mm/3Inch
Coil Material : SV-W
Number of Layers : 2 (Outside)
Former Material : Aluminium
Cone Material : Paper
Surround Material : Cloth
Spider : Single
X-Max : 6Mm/0.231nch
Gap Depth : 8Mm/0.31Inch
Voice Coil Winding Width : 15Mm/0.591nch
Net Weight : 5.99Kg/Pcs
Packaging Dimension : 410*410*380Mm
Shipping Weight : 14.05Kg/Ctn
